PVDF Coated Aluminium

Series: AA1100, 3003, 3004, 3105, 5006, 5052, 8011, etc.

Thickness: 0.08-1.5mm

Width: ＜1800mm

Application: aluminum composite panel, aluminum honeycomb, fireproof veneer, aluminum ceiling, shutters, roller shutter door, etc.

Color: According to your

Send Inquiry Send Email

Related Products
Related Blogs
Related Applications
Related Videos

HENAN HC ALUMINUM CO., LTD

Tel: +86-371-58525958

Email: sales@aluhc.com

Website: https://www.aluhc.com

OFFICE ADDRESS: 1107, Lujin Building, CBD, ZHENGHZOU, HENAN CHINA
CONTACT: MR. MA
CELL/Whatsapp: 008618137889531

Product Introduction

PVDF painted aluminum coil is the most popular new material at present. The stable chemical structure of PVDF enables this coating excellent weather resistance performance, anti-ultraviolet performance, super long durability and anti-corrosion performance, which can maintain very bright and glossy color even serving for 20 years in indoor environment.

We also have PE coated aluminum coil for you.

The PVDF paint of pvdf coated aluminium has extremely good gloss and color retention and is in use on many prominent buildings around the world. PVDF is commonly used as insulation on electrical wires, because of its combination of flexibility, low weight, low thermal conductivity, high chemical-corrosion resistance, and heat resistance.

Types of PVDF Color Coated Aluminum Coil

PVDF coating also can be classified as traditional PVDF and nanometer PVDF coating.

1. Traditional PVDF coating, with KYNAR500 PVDF can keep 15 years no color fading in atrocious weather and environment. Therefore, we recommend this panel for external wall cladding.

2. Nanometer PVDF coating, with nanometer element, has self-cleaning effect, so it is free from the pollution of rain or water.

3. Two types of coated aluminum coils both have many colors:white, black, gold, brown, etc.

Specification of PVDF aluminium colour coated coils

Substrates	AA1100, 3003, 3004, 3105, 5006, 5052, 8011, etc.
Thickness	0.08-1.5mm
Width	＜1800mm
Coils core diameter	150mm ,405mm, 505mm, 508mm, 510mm
Coating thickness	PVDF >=25micron POLYESTER>=18micron
Color standard	E < 2 or it is not obvious by eyeballing
Pencil hardness	> 2HB
Coating adhesive	not lower than first grade Impact: no any crack (50kg/cm, ASTMD-2794:1993)
Bend strength	>100 times
Boiling point	no any distortion and color change (in the 99 more or less 1 degree water, then cooling 2 hours)
Corrosive	surface deep in the 5% muriatic acid and 5% NaCL, interior deep in the 2% muriatic acid and 2% NaCL, after 48 hours, no change
